Concrete Faced Insulated Perimeter Wall Panels
WallGUARD® insulates and protects areas from just below grade to where your heat lost begins around the exposed area of your building foundation. Around the slab edge or rim joist is an area that can account for 10% or more of your total heat loss. WallGUARD stops that heat loss and provides a durable latex modified concrete finish that can stand up to accidental impact. WallGUARD comes standard in a gray concrete, but can be coated on-site to provide a color or texture match to your exterior design features.
WallGUARD is manufactured using Styrofoam extruded polystyrene insulation, with a factory-applied 5/16-inch latex-modified concrete coating. Panels are 2’x4′ with tongue-and-groove edges on the 4′ length. WallGUARD comes in either 2″ (R-10) or 3″ (R-15) thicknesses of Styrofoam and is attached with a hidden clip system that is provided with each pallet of product.
